SPECIFICATIONS
Metric With ratchet stop
| Order No. | Range | Graduation | Accuracy |
|---|---|---|---|
| 193-101 | 0 – 25mm | 0.01mm |
±2µm |
| 193-111 | 0.001mm | ||
| 193-102 |
25 – 50mm |
0.01mm | |
| 193-112 | 0.001mm | ||
| 193-103 |
50 – 75mm |
0.01mm | |
| 193-113 | 0.001mm | ||
| 193-104 | 75 – 100mm | 0.01mm | ±3µm |
| 193-114 | 0.001mm |
Inch With ratchet stop
| Order No. | Range | Graduation | Accuracy |
|---|---|---|---|
| 193-213 | 2″ – 3″ | .0001″ | ±.0001″ |
| 193-214 | 3″ – 4″ | ±.00015″ |
Inch With friction thimble
| Order No. | Range | Graduation | Accuracy |
|---|---|---|---|
| 193-211 | 0 – 1″ | .0001″ | ±.0001″ |
| 193-212 | 1″ – 2″ |
Metric Micrometer set
| Order No. | Range | Models included |
|---|---|---|
| 193-901 | 0 – 75mm
(3 pcs./set) |
• 193-101, 193-102, 193-103
• 2 micrometer standards |
|
193-902 |
0 – 100mm
(4 pcs./set) |
• 193-101, 193-102,
193-103, 193-104 • 3 micrometer standards |
Inch Micrometer set
| Order No. | Range | Models included |
|---|---|---|
| 193-923 | (3 0 – 3″ | • 193-211, 193-212, 193-213 |
DIMENSIONS
| Range | a | b | c | d |
|---|---|---|---|---|
| 0 – 25mm | 5 | 26 | 2.5 | 30 |
| 25 – 50mm | 8 | 32 |
2.0 |
55 |
| 50 – 75mm | 9 | 45 | 80 | |
| 75 – 100mm | 57 | 105 |
Technical Data
Counter Reading : 0.01mm or .001″
Flatness: 0.6µm/.000024″
Parallelism: (2 + R/100)µm, R = max. range (mm)
[.00008″ + .00004(R/4)]” R = max. range (inch)
fraction rounded down
Standard accessories: Reference bar, 1 pc
(except for measuring range 0-25mm (0-1″) models)
Spanner (301336), 1 pc
