| Code | Length (mm) | Flatness of A and B | Parellelism between A and B | H (mm) | W (mm) | D (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| 4180-500 | 500 | 3μm | 4μm | 60 | 30 | 5 | 1 |
| 4180-1000 | 1000 | 5μm | 8μm | 60 | 30 | 5 | 1.5 |
| 4180-1500 | 1500 | 15μm | 22μm | 100 | 40 | 7 | 4.5 |
| 4180-2000 | 2000 | 18μm | 27μm | 100 | 40 | 7 | 6 |
| 4180-2500 | 2500 | 22μm | 33μm | 100 | 40 | 7 | 7.5 |
| 4180-3000 | 3000 | 48μm | 72μm | 150 | 80 | 8 | 21 |
