LARGE DIAMETER GAGE CODE ISQ-RA500

Name: LARGE DIAMETER GAGE CODE ISQ-RA500
Brand: INSIZE
SKU: Ø500 ~ 6000mm

Code:

To measure large external or internal diameters Automatic judgment and display external (EXT) or internal diameter (INT) Carbon fiber handle, light in weight Backlight LCD display, can rotate 180 ° for easy reading Memory of 10 readings and average calculation With minimum measurement mode (MIN) Angle can be displayed Specification Range EXT Range INT Resolution

f in

Click to Expand

LARGE DIAMETER GAGE CODE ISQ-RA500

Product Overview

The INSIZE Large Diameter Gage (Code ISQ-RA500) is a precision measuring instrument designed for measuring large external and internal diameters. Featuring a lightweight carbon fiber handle and an automatic judgment system to detect and display external (EXT) or internal diameter (INT) modes, this gage delivers reliable and accurate dimensional verification.

Key Features & Capabilities

Designed to measure large external or internal diameters
Automatic judgment and display of external (EXT) or internal diameter (INT) measurement modes
Lightweight carbon fiber handle construction
Backlight LCD display that can rotate 180° for easy reading
Memory capacity of 10 readings with built-in average calculation
Minimum measurement mode (MIN)
Angle display capability

Technical Specifications

Parameter	Specification
Brand	INSIZE
Model / Code	ISQ-RA500
External Measuring Range (Range EXT)	Ø500 ~ 6000 mm
Internal Measuring Range (Range INT)	Ø1100 ~ 6000 mm
Resolution	0.01 mm
Accuracy	±(0.02 + 0.1D²) mm (where D is the diameter to be measured in meters)
Power Supply	Rechargeable battery (supports 6 hours of working time)
Weight	3.8 kg
