MICROMAR 40 AS – MICROMETER FOR MEASURING RECESSES, GROOVES, ETC.

MICROMAR 40 AS MICROMETER

Technical Data

Order no. Measuring range mm Graduation value mm Error limit µm Spindle thread pitch_mm Measuring force (N)
4134200
0 – 25
0,01
4 µm
0.5 mm
5 – 10
4134201
25 – 50
0,01
4 µm
0.5 mm
5 – 10
4134202
50 – 75
0,01
5 µm
0.5 mm
5 – 10
4134203
75 – 100
0,01
5 µm
0.5 mm
5 – 10



MICROMAR 40 AS MICROMETER

Technical Data

Order no. Measuring range inches Graduation value inch Error limit inches Micrometer pitch (inches) Measuring force (N)
4134930
0 – 1″
.0001”
.00016″
.025″
5 – 10
4134931
1 – 2″
.0001”
.00016″
.025″
5 – 10
4134932
2 – 3″
.0001”
.0002″
.025″
5 – 10
4134933
3 – 4″
.0001”
.0002″
.025″
5 – 10
