MITUTOYO SERIES 293 QuantuMike Micrometer

Accurate and highly environmentally resistant, assisting with many types of measurements
Ratchet thimble provides better operability for one-handed operation.
Oil-resistant material used for all plastic parts.
Models equipped with a Digimatic output port can form part of a statistical process control or networked measurement system.

Metric With ratchet stop

Code No.	Range (mm)	Resolution (mm)	Measuring force (N)	Measuring permissible error JMPE (μm)	Flatness (μm)	Parallelism (μm)	Mass (g)
Without SPC data output
293-821-30	0 – 25	0.001	5 – 10	±2	0.3	2	270

Inch / Metric With ratchet stop

Code No.	Range (mm)	Resolution (mm)	Measuring force (N)	Measuring permissible error JMPE (μm)	Flatness (μm)	Parallelism (μm)	Mass (g)
Without SPC data output
293-831-30	0 – 1	0.00005 in / 0.001 mm	5 – 10	±0.0001	0.000012	0.00008	270

Inch / Metric With friction thimble

Code No.	Range (mm)	Resolution (mm)	Measuring force (N)	Measuring permissible error JMPE (μm)	Flatness (μm)	Parallelism (μm)	Mass (g)
Without SPC data output
293-832-30	0 – 1	0.00005 in / 0.001 mm	5 – 10	±0.0001	0.000012	0.00008	270

Power source: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
Battery life: Approx. 2.4 years under normal use
Position detection method: Electromagnetic rotary sensor
Spanner (301336), 1 pc.

Functions

Zero-setting: A brief press on the ORIGIN button sets display to zero at the current spindle position (zero-setting), which allows easy comparison measurement.
Auto power ON/OFF: The reading on the LCD disappears after this instrument is idle for about 20 minutes, but the reading is retained.
Turning the spindle causes the reading on the LCD to reappear.
Error display: In case of an overflow on the LCD or a computing error, an error message appears on the LCD, and the measuring function stops. This prevents an instrument from giving an erroneous reading. Also, when the battery voltage drops to a certain level, the low-battery-voltage alarm indicator appears well before the micrometer becomes unusable.
