INSIZE Large Range Internal Dial Caliper Gages (Code 2334)

INTERNAL DIAL CALIPER GAUGES

Code	Range (mm)	Graduation	Accuracy	Type	L (mm)
2334-155	135-155	0.01mm	±0.04mm	A	<200
2334-175	155-175	0.01mm	±0.04mm	A	<200
2334-195	175-195	0.01mm	±0.04mm	A	<200
2334-215	195-215	0.01mm	±0.04mm	A	<200
2334-235	215-235	0.01mm	±0.04mm	A	<200
2334-255	235-255	0.01mm	±0.04mm	A	<200
2334-275	255-275	0.01mm	±0.04mm	A	<200
2334-295	275-295	0.01mm	±0.04mm	A	<200
2334-315	295-315	0.01mm	±0.04mm	A	<200
2334-335	315-335	0.01mm	±0.04mm	B	<200
2334-355	335-355	0.01mm	±0.04mm	B	<200
2334-375	355-375	0.01mm	±0.04mm	B	<200
