Wide range of inside diameter measurements possible by combining one or more interchangeable rods. Each interchangeable rod is marked with its measuring range. For models supplied with more than one interchangeable rod, the full measuring range is achieved by combining spacing collars with the rods. Both micrometer head and rods are satinchrome finished throughout. The sleeve is rotated

SPECIFICATIONS

Metric

Order No.	Range	Graduation	Micrometer head stroke	Remarks
141-001 / 141-003*	25 – 32mm	0.01mm	7mm	—
141-101 / 141-103*	25 – 50mm		7mm	with 2 rods
141-025 / 141-027*	50 – 63mm		13mm	—
141-205 / 141-211*	50 – 200mm			with 3 rods
141-206 / 141-212*	50 – 300mm			with 5 rods
141-009 / 141-011*	200 – 225mm		25mm	—
141-117	200 – 500mm			with 3 rods
141-118	200 – 1000mm			with 8 rods

* with carbide measuring face

Inch

Order No.	Range	Graduation	Micrometer head stroke	Remarks
141-002 / 141-004*	1” – 1.25”	.001″	.25”	—
141-102 / 141-104*	1” – 2”		.25”	with 2 rods
141-026 / 141-028*	2” – 2.5”		.5”	—
141-208 / 141-214*	2” – 8”			with 3 rods
141-233 / 141-215*	2” – 12”			with 5 rods
141-010 / 141-012*	8” – 9”		1”	—
141-121	8” – 20”			with 3 rods
141-122	8” – 40”			with 8 rods

* with carbide measuring face

DIMENSIONS

Inside Micrometers

Technical Data
Accuracy
±(6+maximum measurement length/50)µm (fraction rounded up)

Inside Micrometers

Wide range of inside diameter measurements possible by combining one or more interchangeable rods.
Each interchangeable rod is marked with its measuring range.
For models supplied with more than one interchangeable rod, the full measuring range is achieved by combining spacing collars with the rods.
Both micrometer head and rods are satinchrome finished throughout.
The sleeve is rotated to adjust the index line position when setting to a length standard.
Setting ring (nominal size below 300mm), CERA Inside Micro Checker, and Gauge Block accessory set are provided as a reference gage for datum adjustment (refer to page C-47, C-26, and E-17 – E20 for details).
