Mitutoyo-Series 342,112,142-Crimp Height Micrometers

MITUTOYO-SERIES 342,112,142-CRIMP HEIGHT MICROMETERS

Measures the height of crimp contacts. Equipped with Ratchet Stop for constant measuring force. IP65 water/dust protection (digital model). Model 342-451 is the Quickmike type, which provides a speedy spindle feed of 10mm per thimble rotation, which enables widely differently sized features to be measured quickly. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic (LCD) 342-271-30 0

SPECIFICATIONS

Metric

Order No.	Range	Resolution	Accuracy*
Digimatic (LCD)
342-271-30	0 – 20mm	0.001mm	±3µm
Quickmike (LCD)
342-451	0 – 15mm	0.001mm	±3µm

* Excluding quantizing error

Inch/Metric

Order No.	Range	Resolution	Accuracy*
Digimatic (LCD)
342-371-30	0 – .8″	.00005″/ 0.001mm	±.00015″

* Excluding quantizing error

Metric

Order No.	Range	Graduation	Accuracy
Mechanical counter model
142-402	0 – 25mm	0.01mm	±3µm
142-403	0.001mm

Order No.

Range

Graduation

Accuracy

Mechanical counter model

142-402

0 – 25mm

0.01mm

±3µm

142-403

0.001mm

Metric

Order No.	Range	Graduation	Accuracy
Analog
112-401	0 – 25mm	0.01mm	±3µm

DIMENSIONS

Crimp Height Micrometers

IP Codes (series 342-271-30, 342-371-30)
Level 6: Dust-proof.
No ingress of dust allowed.
Level 5: Protected against water jets.
Water projected in jets against the enclosure
from any direction shall have no harmful effects.

Crimp Height Micrometers

Battery for series 342
SR44 (1 pc), 938882, for initial operational checks
(standard accessory)
Battery life: Approx. 2.4 years under normal use
(for series 342-271-30/342-371-30)
Approx. 3 years under normal use
(for series 342-451)
Length standard: Electromagnetic rotary sensor
(for series 342-271-30/342-371-30)
Electrostatic capacity absolute sensor
(for series 342-451)
Standard accessories:
Spanner (301336), 1 pc (except for series 342-451)

Optional accessories
Connecting cables (digital model)
1m: 05CZA662
2m: 05CZA663
USB Input Tool Direct
USB-ITN-B (2m): 06ADV380B
Connecting cables for U-WAVE-T (digital model)
02AZD790B (160mm)
For foot switch: 02AZE140B
Connecting cables (Quickmike type)
1m: 937387
2m: 965013

USB Input Tool Direct
USB-ITN-E (2m): 06ADV380E
Connecting cables for U-WAVE-T (Quickmike type)
02AZD790E 160mm
For foot switch: 02AZE140E
Refer to page B-68 for details.

Measures the height of crimp contacts.
Equipped with Ratchet Stop for constant measuring force.
IP65 water/dust protection (digital model).
Model 342-451 is the Quickmike type, which provides a speedy spindle feed of 10mm per thimble rotation, which enables widely differently sized features to be measured quickly.
