Type A
| Code | Range | Accuracy | L (mm) | b (mm) |
|---|---|---|---|---|
| 3232-25A | 0-25mm | 4μm | 57 | 32 |
| 3232-50A | 25-50mm | 4μm | 82 | 44.5 |
| 3232-75A | 50-75mm | 5μm | 107 | 57 |
| 3232-100A | 75-100mm | 6μm | 132.6 | 69.5 |
| 3232-125A | 100-125mm | 6μm | 158 | 82 |
| 3232-150A | 125-150mm | 6μm | 183.4 | 94.5 |
| 3232-175A | 150-175mm | 7μm | 208.8 | 107 |
| 3232-200A | 175-200mm | 7μm | 234.2 | 129.6 |
| 3232-225A | 200-225mm | 8μm | 259.6 | 142.3 |
| 3232-250A | 225-250mm | 8μm | 285 | 155 |
| 3232-275A | 250-275mm | 9μm | 310.4 | 167.7 |
| 3232-300A | 275-300mm | 9μm | 336.5 | 177.8 |
Type B
| Code | Range | Accuracy | L (mm) | b (mm) |
|---|---|---|---|---|
| 3232-25BA | 0-25mm | 4μm | 57 | 32 |
| 3232-50BA | 25-50mm | 4μm | 82 | 44.5 |
| 3232-75BA | 50-75mm | 5μm | 107 | 57 |
| 3232-100BA | 75-100mm | 6μm | 132.6 | 69.5 |
| 3232-125BA | 100-125mm | 6μm | 158 | 82 |
| 3232-150BA | 125-150mm | 6μm | 183.4 | 94.5 |
| 3232-175BA | 150-175mm | 7μm | 208.8 | 107 |
| 3232-200BA | 175-200mm | 7μm | 234.2 | 129.6 |
| 3232-225BA | 200-225mm | 8μm | 259.6 | 142.3 |
| 3232-250BA | 225-250mm | 8μm | 285 | 155 |
| 3232-275BA | 250-275mm | 9μm | 310.4 | 167.7 |
| 3232-300BA | 275-300mm | 9μm | 336.5 | 177.8 |
