MICROMAR 40 EWR-B DIGITAL MICROMETER

MICROMAR 40 EWR-B DIGITAL MICROMETER

Reduced measuring surfaces Ø 3 mm High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated USB Digimatic Opto RS232C Battery life approx. 2 years IP 65 instruction manual battery setting standard (measuring range of

Reduced measuring surfaces Ø 3 mm
High contrast analog display
Stainless spindle is hardened throughout and ground
Spindle and anvil are carbide tipped
Rapid drive
Ratchet is integrated in the thimble
Lacquered steel frame, heat insulated
USB
Digimatic
Opto RS232C
Battery life approx. 2 years
IP 65
instruction manual
battery
setting standard (measuring range of 25-50 mm)
case

Height of Digits

8.5mm

Technical Data

Order no.	Measuring range mm	Measuring range inches	Resolution mm/inch	Spindle diameter	Spindle thread pitch_mm	Measuring force (N)
4151750	0 – 25	0 – 1″	0.001 / .00005″	6.5 mm	0.635 mm	5 – 10
4151751	25 – 50	1 – 2″	0.001 / .00005″	6.5 mm	0.635 mm	5 – 10
4151752	50 – 75	2 – 3″	0.001 / .00005″	6.5 mm	0.635 mm	5 – 10
4151753	75 – 100	3 – 4″	0.001 / .00005″	6.5 mm	0.635 mm	5 – 10
